Services available for AR500 Steel

Tumbling

Minimize surface imperfections and handling scratches commonly found in raw materials.

Learn More

Material Details

.119" AR500

AR500 .119" General Details INCH MM
Advertised Thickness 0.119" 3.023 mm
Gauge 11 11
Thickness tolerance positive 0.030" 0.762 mm
Thickness tolerance negative 0.030" 0.762 mm
Mill Finish Hot Rolled Hot Rolled
Top/Bottom finish Identical both sides Identical both sides
Sourced from USA/Global USA/Global
Laser Cutting Specification INCH MM
Cutting process Fiber laser Fiber laser
Cut tolerance +/- 0.005" 0.127 mm
Flatness tolerance before cutting +/-0.030 per foot +/-0.030 per foot
Min part size .25″ x .375″ 6.35 mm x 9.525 mm
Max part size 44″ x 30″ 1117.6 mm x 762 mm
Min hole size .042″ 1.067 mm
Min bridge size .060″ 1.524 mm
Min hole to edge distance .036" 0.914 mm
Tab and slot tolerance .035" 0.889 mm
Tumble Specifications INCH MM
Min Part Size Tumbling 0.5″ x 1.5″ 12.7 mm x 38.1 mm
Max Part Size Tumbling 4″ x 7″ 101.6 mm x 177.8 mm
AR500 .119" Properties INCH MM
Material Composition Iron (Fe): 95.6 Nickel (Ni): 1.0 Manganese (Mn): 0.95 Chromium (Cr): 0.75 Molybdenum (Mo): 0.75 Silicon (Si): 0.65 Carbon (C): 0.31 Phosphorus (P): 0.025 Sulfur (S): 0.0050 Boron (B): 0.0030 Iron (Fe): 95.6 Nickel (Ni): 1.0 Manganese (Mn): 0.95 Chromium (Cr): 0.75 Molybdenum (Mo): 0.75 Silicon (Si): 0.65 Carbon (C): 0.31 Phosphorus (P): 0.025 Sulfur (S): 0.0050 Boron (B): 0.0030
Density 497.66 lb/ft^3 497.66 lb/ft^3
Heat treatments process Quenched Quenched
Tensile Strength (Ultimate) 235 ksi 235 ksi
Tensile Strength (Yield) 200 ksi 200 ksi
Shear Strength 225-240 ksi 225-240 ksi
Shear Modulus 12000 ksi 12000 ksi
Fatigue Strength 16 ksi 16 ksi
Brinell Hardness 477-534 477-534
Elongation at Break 10% 10%
Elastic Modulus 30000 ksi 30000 ksi
Poisson’s Ratio 0.29 0.29
Thermal Conductivity 40 BTU/h-ft °F 40 BTU/h-ft °F
Melting Point 2500 - 2800 °F 2500 - 2800 °F
Magnetic Yes Yes
Does it Rust Yes Yes

.187" AR500

AR500 .187" General Details INCH MM
Advertised Thickness 0.187" 4.75 mm
Gauge N/A N/A
Thickness tolerance positive 0.040" 1.016 mm
Thickness tolerance negative 0.040" 1.016 mm
Mill Finish Hot Rolled Hot Rolled
Top/Bottom finish Identical both sides Identical both sides
Sourced from USA/Global USA/Global
Laser Cutting Specification INCH MM
Cutting process Fiber laser Fiber laser
Cut tolerance +/- 0.005" 0.127 mm
Flatness tolerance before cutting +/-0.030 per foot +/-0.030 per foot
Min part size .25″ x .375″ 6.35 mm x 9.525 mm
Max part size 44″ x 30″ 1117.6 mm x 762 mm
Min hole size .065″ 1.651 mm
Min bridge size .065″ 1.651 mm
Min hole to edge distance .056" 1.422 mm
Tab and slot tolerance .050" 1.27 mm
Tumble Specifications INCH MM
Min Part Size Tumbling 0.5″ x 1.5″ 12.7 mm x 38.1 mm
Max Part Size Tumbling 4″ x 7″ 101.6 mm x 177.8 mm
AR500 .187" Properties INCH MM
Material Composition Iron (Fe): 95.6 Nickel (Ni): 1.0 Manganese (Mn): 0.95 Chromium (Cr): 0.75 Molybdenum (Mo): 0.75 Silicon (Si): 0.65 Carbon (C): 0.31 Phosphorus (P): 0.025 Sulfur (S): 0.0050 Boron (B): 0.0030 Iron (Fe): 95.6 Nickel (Ni): 1.0 Manganese (Mn): 0.95 Chromium (Cr): 0.75 Molybdenum (Mo): 0.75 Silicon (Si): 0.65 Carbon (C): 0.31 Phosphorus (P): 0.025 Sulfur (S): 0.0050 Boron (B): 0.0030
Density 497.66 lb/ft^3 497.66 lb/ft^3
Heat treatments process Quenched Quenched
Tensile Strength (Ultimate) 235 ksi 235 ksi
Tensile Strength (Yield) 200 ksi 200 ksi
Shear Strength 225-240 ksi 225-240 ksi
Shear Modulus 1200 ksi 1200 ksi
Fatigue Strength 16 ksi 16 ksi
Brinell Hardness 477-534 477-534
Elongation at Break 10% 10%
Elastic Modulus 30000 ksi 30000 ksi
Poisson’s Ratio 0.29 0.29
Thermal Conductivity 40 BTU/h-ft °F 40 BTU/h-ft °F
Melting Point 2500 - 2800 °F 2500 - 2800 °F
Magnetic Yes Yes
Does it Rust Yes Yes

.250" AR500

AR500 .250" General Details INCH MM
Advertised Thickness 0.250" 6.35 mm
Gauge N/A N/A
Thickness tolerance positive 0.040" 1.016 mm
Thickness tolerance negative 0.040" 1.016 mm
Mill Finish Hot Rolled Hot Rolled
Top/Bottom finish Identical both sides Identical both sides
Sourced from USA/Global USA/Global
Laser Cutting Specification INCH MM
Cutting process Fiber laser Fiber laser
Cut tolerance +/- 0.005" 0.127 mm
Flatness tolerance before cutting +/-0.030 per foot +/-0.030 per foot
Min part size .500″ x .750″ 12.7 mm x 19.05 mm
Max part size 44″ x 30″ 1117.6 mm x 762 mm
Min hole size .088″ 2.235 mm
Min bridge size .125″ 3.175 mm
Min hole to edge distance .075" 1.905 mm
Tab and slot tolerance .050" 1.27 mm
Tumble Specifications INCH MM
Min Part Size Tumbling 0.5″ x 1.5″ 12.7 mm x 38.1 mm
Max Part Size Tumbling 4″ x 7″ 101.6 mm x 177.8 mm
AR500 .250" Properties INCH MM
Material Composition Iron (Fe): 95.6 Nickel (Ni): 1.0 Manganese (Mn): 0.95 Chromium (Cr): 0.75 Molybdenum (Mo): 0.75 Silicon (Si): 0.65 Carbon (C): 0.31 Phosphorus (P): 0.025 Sulfur (S): 0.0050 Boron (B): 0.0030 Iron (Fe): 95.6 Nickel (Ni): 1.0 Manganese (Mn): 0.95 Chromium (Cr): 0.75 Molybdenum (Mo): 0.75 Silicon (Si): 0.65 Carbon (C): 0.31 Phosphorus (P): 0.025 Sulfur (S): 0.0050 Boron (B): 0.0030
Density 497.66 lb/ft^3 497.66 lb/ft^3
Heat treatments process Quenched Quenched
Tensile Strength (Ultimate) 235 ksi 235 ksi
Tensile Strength (Yield) 200 ksi 200 ksi
Shear Strength 225-240 ksi 225-240 ksi
Shear Modulus 12000 ksi 12000 ksi
Fatigue Strength 16 ksi 16 ksi
Brinell Hardness 477-534 477-534
Elongation at Break 10% 10%
Elastic Modulus 30000 ksi 30000 ksi
Poisson’s Ratio 0.29 0.29
Thermal Conductivity 40 BTU/h-ft °F 40 BTU/h-ft °F
Melting Point 2500 - 2800 °F 2500 - 2800 °F
Magnetic Yes Yes
Does it Rust Yes Yes

.375" AR500

AR500 .375" General Details INCH MM
Advertised Thickness 0.375" 9.525 mm
Gauge N/A N/A
Thickness tolerance positive 0.040" 1.016 mm
Thickness tolerance negative 0.040" 1.016 mm
Mill Finish Hot Rolled Hot Rolled
Top/Bottom finish Identical both sides Identical both sides
Sourced from USA/Global USA/Global
Laser Cutting Specification INCH MM
Cutting process Fiber laser Fiber laser
Cut tolerance +/- 0.005" 0.127 mm
Flatness tolerance before cutting +/-0.030 per foot +/-0.030 per foot
Min part size 1.00″ x 1.00″ 25.4 mm x 25.4 mm
Max part size 44″ x 30″ 1117.6 mm x 762 mm
Min hole size .131″ 3.327 mm
Min bridge size .125″ 3.175 mm
Min hole to edge distance .113" 2.87 mm
Tab and slot tolerance .050" 1.27 mm
Tumble Specifications INCH MM
Min Part Size Tumbling 0.5″ x 1.5″ 12.7 mm x 38.1 mm
Max Part Size Tumbling 4″ x 7″ 101.6 mm x 177.8 mm
AR500 .375" Properties INCH MM
Material Composition Iron (Fe): 95.6 Nickel (Ni): 1.0 Manganese (Mn): 0.95 Chromium (Cr): 0.75 Molybdenum (Mo): 0.75 Silicon (Si): 0.65 Carbon (C): 0.31 Phosphorus (P): 0.025 Sulfur (S): 0.0050 Boron (B): 0.0030 Iron (Fe): 95.6 Nickel (Ni): 1.0 Manganese (Mn): 0.95 Chromium (Cr): 0.75 Molybdenum (Mo): 0.75 Silicon (Si): 0.65 Carbon (C): 0.31 Phosphorus (P): 0.025 Sulfur (S): 0.0050 Boron (B): 0.0030
Density 497.66 lb/ft^3 497.66 lb/ft^3
Heat treatments process Quenched Quenched
Tensile Strength (Ultimate) 235 ksi 235 ksi
Tensile Strength (Yield) 200 ksi 200 ksi
Shear Strength 225-240 ksi 225-240 ksi
Shear Modulus 12000 ksi 12000 ksi
Fatigue Strength 16 ksi 16 ksi
Brinell Hardness 477-534 477-534
Elongation at Break 10% 10%
Elastic Modulus 30000 ksi 30000 ksi
Poisson’s Ratio 0.29 0.29
Thermal Conductivity 40 BTU/h-ft °F 40 BTU/h-ft °F
Melting Point 2500 - 2800 °F 2500 - 2800 °F
Magnetic Yes Yes
Does it Rust Yes Yes

.500" AR500

AR500 .500" General Details INCH MM
Advertised Thickness 0.500" 12.7 mm
Gauge N/A N/A
Thickness tolerance positive 0.040" 1.016 mm
Thickness tolerance negative 0.040" 1.016 mm
Mill Finish Cold Rolled Cold Rolled
Top/Bottom finish Identical both sides Identical both sides
Sourced from USA/Global USA/Global
Laser Cutting Specification INCH MM
Cutting process Fiber laser Fiber laser
Cut tolerance +/- 0.005" 0.127 mm
Flatness tolerance before cutting +/-0.030 per foot +/-0.030 per foot
Min part size 1.00″ x 1.00″ 25.4 mm x 25.4 mm
Max part size 44″ x 30″ 1117.6 mm x 762 mm
Min hole size .250″ 6.35 mm
Min bridge size .250″ 6.35 mm
Min hole to edge distance .150" 3.81 mm
Tab and slot tolerance .050" 1.27 mm
Tumble Specifications INCH MM
Min Part Size Tumbling 0.5″ x 1.5″ 12.7 mm x 38.1 mm
Max Part Size Tumbling 4″ x 7″ 101.6 mm x 177.8 mm
AR500 .375" Properties INCH MM
Material Composition Iron (Fe): 95.6 Nickel (Ni): 1.0 Manganese (Mn): 0.95 Chromium (Cr): 0.75 Molybdenum (Mo): 0.75 Silicon (Si): 0.65 Carbon (C): 0.31 Phosphorus (P): 0.025 Sulfur (S): 0.0050 Boron (B): 0.0030 Iron (Fe): 95.6 Nickel (Ni): 1.0 Manganese (Mn): 0.95 Chromium (Cr): 0.75 Molybdenum (Mo): 0.75 Silicon (Si): 0.65 Carbon (C): 0.31 Phosphorus (P): 0.025 Sulfur (S): 0.0050 Boron (B): 0.0030
Density 497.66 lb/ft^3 497.66 lb/ft^3
Heat treatments process Quenched Quenched
Tensile Strength (Ultimate) 235 ksi 235 ksi
Tensile Strength (Yield) 200 ksi 200 ksi
Shear Strength 225-240 ksi 225-240 ksi
Shear Modulus 12000 ksi 12000 ksi
Fatigue Strength 16 ksi 16 ksi
Brinell Hardness 477-534 477-534
Elongation at Break 10% 10%
Elastic Modulus 30000 ksi 30000 ksi
Poisson’s Ratio 0.29 0.29
Thermal Conductivity 40 BTU/h-ft °F 40 BTU/h-ft °F
Melting Point 2500 - 2800 °F 2500 - 2800 °F
Magnetic Yes Yes
Does it Rust Yes Yes
